(Commscope)UTP Cat.5e 25 Pairs 350MHz,CMR 305MR/PB

OVERVIEW

1499418-1 Copper Cable, Category 5e, 25 Pair, UTP, 100 MHz, CMR rated, 24 AWG, 1000 ft reel, white

Specifications

General

ANSI/TIA Category                                                          5e

Cable Component Type                                                 Horizontal

Cable Type                                                                        U/UTP (unshielded)

Conductor Type, singles                                                 Solid

Conductors, quantity                                                      50

Jacket Color                                                                      White

Pairs, quantity                                                                  25

Transmission Standards                                                 ANSI/TIA-568.2-D | CENELEC EN 50288-6-1 | ISO/IEC 11801 Class D

Dimensions

Cable Length                                                                   304.8 m | 1000 ft

Diameter Over Jacket, nominal                                   12.7 mm | 0.5 in

Conductor Gauge, singles                                             24 AWG

Material Specifications

Conductor Material                                                         Bare copper

Insulation Material                                                          High density polyethylene (HDPE)

Jacket Material                                                                 PVC

Environmental Specifications

Operating Temperature                                                 -20 °C to +60 °C (-4 °F to +140 °F)

Environmental Space                                                      Non-plenum

Environmental Specifications

Packaging Type                                                                 Reel
